Scanning Tunneling Microscope

• Scanning Tunneling Microscope

• Atomically sharp tip, scanning within angstroms above the surface.

• Current an exponential function of the distance of tip from surface--more current as the tip approaches the surface.

• Plot of current with distance represents the atomic scale topography of the surface.

• For practical reasons, STMs operate in constant-current, variable height mode.
